Description	Record # 40
RevDate	Sun, 11 Mar 2007 13:05:00 -0500
Details	This circuit was previously posted by Jason derived from EMRFD. I decided it had too much gain for what I wanted, so the unbypassed emitter resistor is increased from 10 to 100 ohms. This circuit uses 60 mA but should provide a nice high intercept point by using two transistors in parallel.
Schematic=Dual IF Amplifier.jpg.jpg                      Return to SEARCH
